SL-LCD-15C-CTOUCH-3M This item is no longer available.
15" TFT, Active Matrix (CCFL) Monitor with Capacitive Touch Screen - 1024 x 768 Resolution, 250 NITS Brightness, NEMA 1 Front Panel, Black
Industrial Display
- Screen Size (inches): 15"
- Touch Type: Capacitive
- Front Panel Rating: NEMA 1
- Aspect Ratio: 4 : 3
- Native Display Resolution: 1024 x 768
- Brightness (nits): 250
- Ports: VGA Port In
- Mounting Options: VESA 75mm x 75mm, Other options sold separately
- Display
- Screen Size (inches): 15
- Touch Type: Capacitive
- Front Panel Rating: NEMA 1
- Aspect Ratio: 4 : 3
- Native Display Resolution: 1024 x 768
- Brightness (nits): 250
- Display Area (H): 304.10mm
- Display Area (V): 228.10mm
- Aspect Ratio: 4 : 3
- DisplayColors: 16.2 M
- Contrast Ratio: 500:1
- Backlight: TFT, Active Matrix (CCFL)
- Viewing Angle(U) : 75
- Viewing Angle(D) : 75
- Viewing Angle(L) : 75
- Viewing Angle(R) : 75
- Connectivity
- VGA Port In: 1
- Mounting Options
- Mounting Options: VESA 75mm x 75mm, Other options sold separately
- Suggested Cut-Out Dimension (Width): 354mm
- Suggested Cut-Out Dimension (Height): 280mm
- Physical
- Width: 13.80"
- Height: 11"
- Depth: 2"
- Depth (Inches): 2
- Unboxed Weight: 9.2lbs
- Shipping Weight: 16lbs
- Environmental
- MTBF: 50,000hours
- Maximum Operating Temperature: 40C
- High Humidity: 90%
- Low Humidity: 5%
- Storage Temp (High): 60C
- Storage Temp (Low): -20C
- Storage Humidity (High): 90%
- Storage Humidity (Low): 5%
- Power
- Power Supply: Accepts 110/220V AC Power directly or 12VDC
- Power Consumption (on): 28Watts
- Compliance of Component
- UL
- CE
- FCC
- Warranty
- Warranty: 3 years
- Other
- Features:
- Screen Size: 15"
- Touch Type: Capacitive
- Front Panel Rating: Not Rated
- Native Display Resolution: 1024 x 768
- Brightness (nits): 250
- NEMA 1
