SL-MOBILE-GT78V8 This item is no longer available.

8" TFT color LCD 1280x800 WXGA resolution with P-cap Multi-Touch..Embedded 1D/2D barcode imager and 5MP front camera and 13MP AF rear camera with flashlight, High mobility with multiple-connectivity including WLAN

A newer version of this item is available: Galaxy-Active4-Pro-64GB-UNLK
  • 8" TFT color LCD 1280 x 800 WXGA resolution with P-cap Multi-Touch
  • Embedded 1D/2D barcode imager and 5MP front camera and 13MP AF rear camera with flashlight
  • Field replaceable battery with optimized battery life up to 8 hours
  • High mobility with multiple-connectivity including WLAN and WWAN
  • MIL-STD-810G compliant, 1.2m (4ft.) drop resistance
  • Fully rugged IP65 enclosure to protect from dust and water
  • Node-Watch supported to unified manage mobile devices, apps, and contents

System

CPU                           Quad Core ARM Cortex-A53 1.3GHz

OS                              Android™ 7.0

Memory                     3GB LPDDR2

Flash                         16 GB eMMC (32 GB option)

LCD Display

Size/Type                  8” TFT LCD

Resolution               1280 x 800

Brightness               400 nits

Touch Screen          5-point capacitive touch (PCT)

Peripherals and Devices

Camera

  • Front: 5M
  • Rear: 13M AF with Flashlight

Sensor

  • Magnetometer (M-Sensor/E-Compass)
  • Accelerometer (G-sensor)
  • Gyroscope
  • Ambient light sensor
  • Barometer

Barcode Scanner   2D barcode reader (N6603), w/ physical trigger button

Audio & Vibrator

  • 1 x built-in microphone
  • 1 x built-in speaker (1.5W)
  • 1 x vibrator

Wireless

WLAN                      IEEE 802.11 a/b/g/n

WWAN (ME909s-120) Optional 1

  • 2G GSM/GPRS/EDGE (Band 850 / 900 / 1800 / 1900)
  • 3G WCDMA (Band 1,2,5,8)
  • LTE (Band 1,2,3,4,5,7,8,20)

WWAN (NL-SWLTES7588-Verizon) Optional 2

  • 3G WCDMA (Band 2,5)
  • LTE (Band 2,4,5,12,13,17)

Navigation

  • GPS/Glonass
  • GPS/Beidou (Option)

NFC

  • ISO 15693 ; ISO 14443A ; ISO 14443B, B’ ;
  • ISO 18000-3 ; NFC Forum Type1-4 Tag ; Kovio

I/O Interface

USB Port                 1 x micro USB 2.0 port High Speed/ OTG Compatible

SD Slot                    1 x microSD card slot (max 64G)

SIM Socket              1 x micro-SIM (3FF) socket supporting 2G/ 3G/ LTE

Pogo pin                  Extra power pins for vehicle bracket; 5V/2A*

For USB charging, the GT-78V can use 9V/2A and 5V/2A USB charger adapter. For pogo pin, the charge voltage is 5V/2A only.

Power Supply

Battery Type            Lithium-ion rechargeable battery, field replaceable.

Battery Capacity     Typical 3.7V, 6200mAh

Adapter

Adapter Input          AC 100~240V 50~60 Hz

Adapter Output       9V/2A, 5V/2A

Mechanical

Dimensions             (W x H x D)   220 x 147 x 20.9 mm

Weight                      550g (1.22lb) (with battery)

Ingress Protection   IP65, 1.2m drop

Environmental

Operating Temp.      -10°C ~ 55°C (14°F ~ 131°F )

Storage Temp.          -20°C ~ 65°C (-4°F ~ 149°F)

Operating Humidity  5% ~ 95% RH

Packing Information

Rechargeable Li-ion battery pack         1 x Typical 3.8V, 6200mAh

User Cable                                               1x 1m1
