SL-DK-AZ590I-IC

A newer version of this item is available: SL-EB-Z790A-S15

Desktop PC - Desktop featuring Intel Z590 Chipset, 10th/11th Gen Core i7/i5/i3 (LGA1200), 1x 2.5 Gigabit 10/100/1000/2500 Mb/s LAN, WIFI,Up to 64GB RAM, 2x USB 2.0 Ports ( 2 Internal Headers ), 2x USB 3.2 Gen 1 Ports ( 2 Front ), 5x USB 3.2 Gen 2 Ports ( 5 Rear ), Power Supply 150W 80 PLUS Bronze Adapter Included.

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Type:

Desktop PC
Dimension: 8.60" x 3.30" x 9.60"

Motherboard:

Featuring Intel Z590 Chipset and 10th/11th Gen Core i7/i5/i3 (LGA1200) processor
No Available Slots
LAN: 1x Ports (2.5 Gigabit 10/100/1000/2500 Mb/s)
WiFi: Killer AX1675x 802.11ax Wi-Fi 6E Module
Video: DisplayPort + HDMI
Audio: 7.1 CH HD Audio (Realtek ALC1220 Audio Codec)
Ports:
2x USB 2.0 Ports ( 2 Internal Headers )
2x USB 3.2 Gen 1 Ports ( 2 Front )
5x USB 3.2 Gen 2 Ports ( 5 Rear )
1x Thunderbolt™ 4 (supports USB 4.0) Type-C Port (Rear)
1x Front Audio Port
See specifications for more ports
Operating Temperature: 5ºC to 50ºC (41ºF to 122ºF)

Also Included:

Processor: G5905- 3.50GHz Intel Celeron CPU - Dual Core, 4MB Cache, UHD Graphics 610 (58W)
Memory: 8GB DDR4 3200MHz RAM
Hard Drive: 250GB NVMe SSD M.2 2.9GB/1.3GB - Samsung 980
Power Supply:150W 80 PLUS Bronze Adapter Included
Operating System: Not Included - See options below
Warranty: One-Year Depot Warranty

Configure

Expedite

None show Included

Rush Order - Rush order handling, assembly and testing. Shipping not included. show $100.00

Fast, Fastest. Configure your computer with all QuickShip components and Rush your order for Fastest assembly time. Configure with all QuickShip components for Fast Assembly time.

Processor

G5905- 3.50GHz Intel Celeron CPU - Dual Core, 4MB Cache, UHD Graphics 610 (58W) show $76.00

G5925- 3.60GHz Intel Celeron CPU - Dual Core, 4MB Cache, UHD Graphics 610 (58W) show $50.00

G6400- 4.0GHz Intel Pentium Gold CPU - Dual Core, 4MB Cache, UHD Graphics 610 (58W)Part Delay: No ETA show $109.00

G6500- 4.1GHz Intel Pentium Gold CPU - Dual Core, 4MB Cache, UHD Graphics 630 (58W) show $159.00

i3-10100 - 3.6GHz (up to 4.3GHz) Intel Quad-Core (4 cores) CPU - 6MB Cache, UHD Graphics 630 (65W) show $180.00

i5-10400T - 2.0GHz (up to 3.60GHz) Intel Hexa-Core (6 cores) CPU - 12MB Cache, UHD Graphics 630 (35W)Part Delay: ETA May 10, 2024 show $340.00

i7-10700T - 2.0GHz (up to 4.50GHz) Intel Octo-Core (8 cores) CPU - 16MB Cache, UHD Graphics 630 (35W) show $570.00

i5-11400T - 1.3GHz (up to 3.70GHz) Intel Hexa-Core (6 cores) CPU - 12MB Cache, UHD Graphics 730 (35W) show $350.00

i7-11700T - 1.4GHz (up to 4.60GHz) Intel Octo-Core (8 cores) CPU - 16MB Cache, UHD Graphics 750 (35W) show $685.00

Memory

x 8GB DDR4 3200MHz RAM show $28.00

x 16GB DDR4 3200MHz RAM show $56.00

x 32GB DDR4 3200MHz RAM show $104.00

CD/DVD/OpticalDrive

None show Included

External USB DVD ReWriteable Drive show $51.00

Hard Drive

250GB NVMe SSD M.2 2.9GB/1.3GB - Samsung 980 show $73.00

500GB NVMe SSD M.2 3.1GB/2.6GB - Samsung 980 show $113.00

1TB NVMe SSD M.2 3.5GB/3.0GB - Samsung 980 show $165.00

120GB SSD SATA 6.0Gb/s, 500/320MB/s read/write (or greater) show $30.00

250GB SSD SATA 6.0Gb/s 560/530MB/s 2.5" - Samsung 870 EVO show $75.00

500GB SSD SATA 6.0Gb/s 560/530MB/s 2.5" - Samsung 870 EVO show $99.00

1.0TB SSD SATA 6.0Gb/s 560/530MB/s 2.5" - Samsung 870 EVO show $158.00

2.0TB SSD SATA 6.0Gb/s 560/530MB/s 2.5" - Samsung 870 EVO show $240.00

Additional Hard Drives

120GB SSD SATA 6.0Gb/s, 500/320MB/s read/write (or greater) show $30.00 each

250GB SSD SATA 6.0Gb/s 560/530MB/s 2.5" - Samsung 870 EVO show $75.00 each

500GB SSD SATA 6.0Gb/s 560/530MB/s 2.5" - Samsung 870 EVO show $99.00 each

1.0TB SSD SATA 6.0Gb/s 560/530MB/s 2.5" - Samsung 870 EVO show $158.00 each

2.0TB SSD SATA 6.0Gb/s 560/530MB/s 2.5" - Samsung 870 EVO show $240.00 each

4.0TB SSD SATA 6.0Gb/s 560/530MB/s 2.5" - Samsung 870 EVO show $488.00 each

Networking

None show Included

PRODUCTION NOTE: Remove WiFi Card and Include in the Hardware Kit. show $0.00

Monitors

Asus VP229Q 21.5" Full HD LED LCD Monitor - 16:9 - Black - 22" Class - In-plane Switching (IPS) Techno show $151.00 each

23.8" 16:9 75 Hz Adaptive-Sync IPS Monitor show $150.00 each

27" Monitor, 1080P Full HD, 75Hz, IPS, Adaptive-Sync, Eye Care, HDMI DisplayPort VGA USB Hub, Frameles show $228.00 each

29" HDR10 IPS Full HD UltraWide™ Monitor (2560x1080) with AMD FreeSync™, MAXXAudio®, Flic show $275.00 each

32" 4K UHD 3840 x 2160 Monitor Featuring Wide Color Gamut and FreeSync show $412.00 each

34" Ultra-Wide Freesync HDR Gaming Monitor 75Hz 1440P Eye Care DisplayPort HDMI,Black show $518.00 each

Keyboard/Mouse

USB Keyboard/Mouse - Black/Silver show $24.00 each

Wireless Keyboard/Mouse show $49.00 each

USB Keyboard: Medical Grade True Type 104 Key Layout - Waterproof, NEMA4X/IP66 show $97.00 each

USB Mouse: Medical Grade, 1000 DPI Optical Mouse with Scroll Wheel + 2 Button, Long Cable with Seal Ca show $97.00 each

RF Wireless Medical Grade Washable Keyboard - 99 US Key Layout Waterproof, NEMA4X show $149.00 each

RF Wireless Medical Grade Waterproof Mouse, Antimicrobial Product Protection, 1000 DPI Optical Mouse w show $135.00 each

USB Keyboard/Mouse - Waterproof, NEMA4 show $502.00 each

USB Keyboard/Mouse - Waterproof, IP67/NEMA4x show $672.00 each

External Power

None show Included

Uninterruptable Power Supply - 550VA 300W Standby - 10 NEMA 5-15R Outlets, 120V, 50/60 Hz, USB, 5-15P Plug, Desktop/Wall Mount show $119.00

Uninterruptable Power Supply - 750VA 450W Standby - 12 NEMA 5-15R Outlets, 120V, 50/60 Hz, USB, 5-15P Plug, Desktop / Wall Mount show $164.00

Smart LCD 1500VA 2U Rack/Tower Line-Interactive 120V UPS with LCD display, Expandable Runtime, USB & Serial ports show $610.00

Uninterruptable Power Supply - 350VA, 120V AC, 180Watt, USB, 6 outlets show $120.00

* Required Fields

Technical Specifications

MotherBoard Specifications:

Motherboard Model
Motherboard Type: MiniITX
Supported CPU
Number of Processors: 1
Processor Type: 10th/11th Gen Core i7/i5/i3 (LGA1200)
Chipset
Chipset: Intel Z590 Chipset
Memory
Memory Type: DDR4 2666MHz
Memory Type: Non-ECC
DIMMS: 2
Maximum Memory: 64GB
On Board Audio
Audio Type: 7.1 CH HD Audio (Realtek ALC1220 Audio Codec)
On Board Video
Video Chipset: Supported by CPU - depends on CPU selected
Video on IO: DisplayPort + HDMI
Display Port Out: 1
HDMI Out: 1
LAN
LAN Ports: 1
LAN Type: 2.5 Gigabit 10/100/1000/2500 Mb/s
LAN Chipset: Killer E3100G
Wireless LAN: Killer AX1675x 802.11ax Wi-Fi 6E Module
Drive Interface
SATA III Ports (6GB): 3
RAID Type: Software RAID
RAID Levels Supported on Motherboard: 0, 1, 5, 10
Expansion Slots
PCI Express x16 Slots On Motherboard: 1
M.2 Slot Specs
Total M.2 NVMe SSD Slots: 2
M.2 Slot #1 Specs
PCIe Signal
2280 - 22 mm x 80 mm.
M.2 Slot #2 Specs
M.2 SATA SSD
PCIe Signal
2280 - 22 mm x 80 mm.
Rear IO
USB 3.2 Gen 2 Type A Ports (on IO): 5
Thunderbolt™ 4 (supports USB 4.0) Type-C Port: 1
SPDIF Connector: 1
Audio on IO
Headers
USB 2.0 Ports (on Headers): 2
USB 3.2 Gen 1 Ports (on Headers): 2
FAN Connectors: 3
Audio on Headers
Chassis Intrusion
Environmental
Operating Temperature: 5ºC to 50ºC (41ºF to 122ºF )
High Humidity: 90%
Low Humidity: 5%
Operating System Support
Windows 10 Home (64 Bit)
Windows 10 Pro (64-Bit)
Windows 10 Pro WS (64-Bit)
SL-Windows 11PRO to 10PRO 64bit
Windows 10 IoT Value 2019 LTSC
Windows 10 IoT Ent 2019 LTSC
Windows 10 IoT 2021 LTSC Value
Windows 10 IoT 2021 LTSC High End
Windows 11 Home (64 Bit)
Windows 11 Pro (64 Bit)
Windows 11 Pro for WS (64 Bit)
LINUX Ubuntu Desktop
Ubuntu Server Edition
Compliance of Component
CE
FCC
Other Features
Features:
Note:

*Wi-Fi 6E (6GHz band) is not currently enabled by default due to the different regulation status of each country. It will be activated (for supported countries) through Windows^® Update and software update once available. The update is expected to be in the middle of 2021.

* Access to PCI Express slot requires expansion slot and a riser in some chassis models. Please check Chassis Specification section for more information.

If you have any questions, please discuss with our Sales Engineers.
Motherboard Warranty: 1 Year
