SL-DK-AH270M-ID This item is no longer available.
Microbox PC - Desktop featuring Intel H270 Chipset, 7th and 6th Gen Core i7/i5/i3 (LGA1151), 1x GB (10/100/1000) LAN, 1x Serial, Up to 64GB RAM, 6x USB 2.0 Ports ( 4 Front, 2 Rear ), 7x USB 3.2 Gen 1 Ports ( 3 Rear, 4 Internal Headers ), 1x USB 3.2 Gen 1 Type-C Port (Rear), 4x Expansion Slots, Power Supply 300 Watt Power Supply.
Type:
- Microbox PC
- Dimension: 10.80" x 5.50" x 12.70"
Motherboard:
- Featuring Intel H270 Chipset and 7th and 6th Gen Core i7/i5/i3 (LGA1151) processor
- Full Height Slots:
2 - PCIe x16
2 - PCIe x1 - LAN: 1x Ports (GB (10/100/1000))
- RAID: 0,1
- Video: VGA + HDMI + DVI-D
- Audio: 7.1+2 Channel HD Audio by Realtek ALC892
- Ports:
6x USB 2.0 Ports ( 4 Front, 2 Rear )
7x USB 3.2 Gen 1 Ports ( 3 Rear, 4 Internal Headers )
1x USB 3.2 Gen 1 Type-C Port (Rear)
1x COM Port (RS232 Internal Headers)
1x Front Audio Port
See specifications for more ports - Operating Temperature: 0ºC to 50ºC (32ºF to 122ºF)
Also Included:
- Processor: G4400 - 3.3GHz Intel Pentium Dual Core - 3MB Cache, HD Graphics 510 (54W) (ERM) or Better
- Memory: 8GB DDR4 2666MHz RAM
- Hard Drive: 250GB NVMe SSD M.2 2.9GB/1.3GB - Samsung 980
- Power Supply: 300W SFX-form factor power supply
- Operating System: Not Included - See options below
- Warranty: One-Year Depot Warranty
