SL-EB-LL2930J-S29-4LN This item is no longer available.
Microbox PC - Embedded PC featuring Long Production Cycle Motherboard (Through Q1 2029) with Intel Celeron SoC, Intel Celeron N2930 Processor (1.83GHz Quad Core, Burst 2.16GHz) TDP 7.5W, 4x GB (10/100/1000) LAN, 2x Serial, Up to 8GB RAM, 5x USB 2.0 Ports ( 2 Front, 1 Rear, 2 Internal Headers ), 1x USB 3.2 Gen 1 Port( 1 Rear ), Dimensions of Enclosure: 7.60"L x 8.46"W x 1.77"H, Power Supply AC/DC Power Adapter Included.
Completely Fanless
Type:
- Microbox PC
- Dimension: 193mm x 215mm x 45mm
Motherboard:
- Featuring Intel Celeron SoC and Intel Celeron N2930 Processor (1.83GHz Quad Core, Burst 2.16GHz) TDP 7.5W
- Long Production Cycle Motherboard (Through Q1 2029)
- No Available Slots
- LAN: 4x Ports (GB (10/100/1000))
- Video: Internal VGA
- Audio: No Onboard Audio
- Ports:
5x USB 2.0 Ports ( 2 Front, 1 Rear, 2 Internal Headers )
1x USB 3.2 Gen 1 Port( 1 Rear )
2x COM Port (1 RS232 Internal Headers, 1 RS232/422/485 Rear)
See specifications for more ports - Operating Temperature: 0ºC to 60ºC (32ºF to 140ºF)
Also Included:
- Memory: 4GB DDR3L 1600MHz SODIMM RAM 1.35V
- Hard Drive: 256GB mSATA SSD SATA 6.0Gb/s, 550/500MB/s read/write (or greater)
- Power Supply: AC/DC Power Adapter Included
- Operating System: Not Included - See options below
- Warranty: One-Year Depot Warranty
MotherBoard Specifications:
Chassis Specifications:
CASE-EBOX-S29
