SL-2U-MCX-C621A-R282-TC
2U Rack Mount Server - Rackmount featuring Intel C621A Chipset, Intel® Xeon® Scalable Processors 3rd Gen, 2x GB (10/100/1000) LAN, Up to 2048GB RAM, 2x USB 3.2 Gen 1 Ports ( 2 Rear ), 8x Expansion Slots, Power Supply 2 x 1600W redundant PSUs 80 PLUS Platinum.
Type:
- 2U Rack Mount Server
- Depth: 28.90"
Motherboard:
- Featuring Intel C621A Chipset and Intel® Xeon® Scalable Processors 3rd Gen processor
- Full Height Slots:
3 - PCIe x16
5 - PCIe x8 - LAN: 2x Ports (GB (10/100/1000))
- RAID: 0,1,5,10
- Video: VGA
- Audio: No Onboard Audio
- Ports:
2x USB 3.2 Gen 1 Ports ( 2 Rear )
See specifications for more ports - Operating Temperature: 10ºC to 35ºC (50ºF to 95ºF)
Also Included:
- Processor: 2 x 3rd Gen Xeon Silver 4310 - 2.1GHz (up to 3.3GHz) Twelve Core Intel Processor - 18MB Cache (120W)
- Memory: 4 x 8GB DDR4 2666MHz ECC Registered RAM
- Hard Drive: 1.0TB SATA 6Gb/s 7200RPM 128MB 3.5" - EXOS 7E2 Series
- Power Supply: 2 x 1600W redundant PSUs 80 PLUS Platinum
- Operating System: Not Included - See options below
- Warranty: One-Year Depot Warranty
MotherBoard Specifications:
- Motherboard Model
- Motherboard Type: Proprietary
- Supported CPU
- Number of Processors: 2
- Processor Type: Intel® Xeon® Scalable Processors 3rd Gen
- Chipset
- Chipset: Intel C621A Chipset
- Memory
- Memory Type: DDR4 2666MHz ECCR
- Memory Type: ECC Registered
- DIMMS: 32
- Maximum Memory: 2048GB
- On Board Audio
- Audio Type: No Onboard Audio
- On Board Video
- Video Chipset: ASPEED AST2500 BMC
- Video on IO: VGA
- VGA Port Out: 1
- LAN
- LAN Ports: 2
- LAN Type: GB (10/100/1000)
- LAN Chipset: Intel® i350
- Second LAN Chipset: Intel® i350
- Wireless LAN: No Integrated WLAN
- Drive Interface
- SATA III Ports (6GB): 14
- RAID
- RAID Type: Software RAID
- RAID Levels Supported on Motherboard: 0, 1, 5, 10
- Expansion Slots
- PCI Express x16 Slots On Motherboard: 3
- PCI Express x8 Slots On Motherboard: 5
- Rear IO
- USB 3.2 Gen 1 Type A Ports (on IO): 2
- Headers
- FAN Connectors: 4
- Management Features
- IPMI
- TPM Support: Via 2.0 Header
- Environmental
- Operating Temperature: 10ºC to 35ºC (50ºF to 95ºF )
- High Humidity: 80%
- Low Humidity: 8%
- Operating System Support
- Ubuntu Server Edition
- Windows Server 2019 Std
- RED HAT Enterprise LINUX SERVER BASIC
- RED HAT Enterprise LINUX WORKSTATION STANDARD
- RED HAT Enterprise LINUX SERVER STANDARD
- VMWare Compatible
- Warranty of Component
- Motherboard Warranty: 3 Years
- Other Features
- Other Features:
1 x PCIe x16 slot (Gen4 x16), Full height half-length
2 x PCIe x8 slots (Gen4 x8), Full height half-length1 x PCIe x16 slot (Gen4 x16 or x8), Full height half-length
1 x PCIe x8 slots (Gen4 x0 or x8), Full height half-length
1 x PCIe x16 slot (Gen4 x16 or x8), shared with OCP 2.0, Full height2 x PCIe x8 slots (Gen4 x8), Low profile half-length
Chassis Specifications:
- General
- Form Factor: 2U Rackmount
- Color: Black & Silver
- Material: Steel & Plastic
- Material Thickness: 1mm
- Redundant Power Supply Capable
- Slide Rails: Included
- Expansion
- Full Height Slots: 6
- Low Profile Slots: 2
- 2.5" Hot Swap Bays: 2
- 3.5" or 2.5" Hot Swap Bays: 12
- Front Ports
- USB 3.2 Ports (Front): 2
- Cooling System
- Maximum Fan Count: 4
- Included Fans: 4
- Physical
- Depth: 28.90"
- Width: 17.25"
- Height: 3.45"
- Shipping Box - Depth: 39"
- Shipping Box - Width: 24"
- Shipping Box - Height: 11"
- Shipping Weight: 65lbs
- Power
- Built-in Chassis Power Supply: 2 x 1600W redundant PSUs 80 PLUS Platinum
- Other Features
- Features:
8 x 3.5" or 2.5" SATA/SAS hot-swappable HDD/SSD bays
4 x 3.5" or 2.5" SATA/SAS/Gen4 NVMe hot-swappable HDD/SSD bays
2 x 2.5" SATA/SAS hot-swappable HDD/SSD bays in rear side
SAS card is required for SAS devices support
