SL-3U-WRX80-GM62-SE

3U Rack Mount Server - Rackmount featuring AMD WRX80, AMD Socket sWRX8 for Ryzen™ Threadripper™ PRO Series, 4x 10GbE + 10GbE + 1GbE + IPMI LAN, 1x Serial, Up to 2048GB RAM, 4x USB 3.2 Gen 1 Ports ( 2 Front, 2 Internal Headers ), 5x USB 3.2 Gen 2 Ports ( 5 Rear ), 1x USB 3.2 Gen 2 Type-C Port ( 1 Rear ), 7x Expansion Slots.

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Type:

3U Rack Mount Server
Depth: 16.89", Max Card Depth: 375mm"

Motherboard:

Featuring AMD WRX80 and AMD Socket sWRX8 for Ryzen™ Threadripper™ PRO Series processor
Full Height Slots:
7 - PCIe x16
LAN: 4x Ports (10GbE + 10GbE + 1GbE + IPMI)
RAID: 0,1 NVMe Only
Video: VGA
Audio: Realtek® ALC4080 codec
Ports:
4x USB 3.2 Gen 1 Ports ( 2 Front, 2 Internal Headers )
5x USB 3.2 Gen 2 Ports ( 5 Rear )
1x USB 3.2 Gen 2 Type-C Port ( 1 Rear )
1x COM Port (RS232 Internal Headers)
See specifications for more ports
Operating Temperature: 10ºC to 40ºC (50ºF to 104ºF)

Also Included:

Processor: i7-9800X - 3.8GHz (up to 4.4GHz) Intel Octa (8) Core CPU - 16.5MB Cache, No Onboard Graphics (165W)
Memory: 2 x 8GB DDR4 3200MHz OC RAM
Hard Drive: 1TB PCIe 4.0 NVMe SSD M.2 7,000MBps/5,000MBps - Samsung 980 PRO
Add-In Graphic Card: NVIDIA Quadro T400 4GB 64-bit GDDR5 PCIe 3.0 x16 Workstation Video Card - 3 x Mini DisplayPort 1.4 - No Win 7 Support!
Power Supply: 650W SFX Form Factor Auto-Switching Power Supply, Fully Modular, 80+ Gold
Operating System: Not Included - See options below
Warranty: One-Year Depot Warranty

Configure

Expedite

None show Included

Rush Order - Rush order handling, assembly and testing. Shipping not included. show $100.00

Fast, Fastest. Configure your computer with all QuickShip components and Rush your order for Fastest assembly time. Configure with all QuickShip components for Fast Assembly time.

Processor

AMD Ryzen Threadripper PRO 5955WX, 16-Core, 32-Thread, 4.0GHz, Socket sWRX8 Processor show $1,870.00

AMD Ryzen Threadripper PRO 5965WX, 24-Core, 48-Thread, 3.8GHz, Socket sWRX8 Processor show $3,973.00

AMD Ryzen Threadripper PRO 5975WX, 32-Core, 64-Thread, 3.6GHz, Socket sWRX8 Prcoessor show $4,475.00

AMD Ryzen Threadripper PRO 5995WX, 64-Core, 128-Thread, 2.7GHz, Socket sWRX8 Processor show $9,690.00

Memory

x 8GB DDR4 3200MHz OC RAM show $48.00

x 16GB DDR4 3200MHz RAM show $65.00

x 32GB DDR4 3200MHz OC RAM show $106.00

x 8GB DDR4 3200MHz ECC Registered RAM show $45.00

x 16GB DDR4 3200MHz ECC Registered RAM show $76.00

x 32GB DDR4 3200MHz ECC Registered RAM show $139.00

x 64GB DDR4 3200MHz ECC Registered RAM show $221.00

Liquid Cooler/Fan (Optional)

240mm high-performance AIO liquid cooler (Requires 2 or 4 120MM FANS) show $82.00

360mm high-performance AIO liquid cooler..(Requires 3 or 6 120MM FANS) show $95.00

Hard Drive

1TB PCIe 4.0 NVMe SSD M.2 7,000MBps/5,000MBps - Samsung 980 PRO show $165.00

2TB PCIe 4.0 NVMe SSD M.2 7,000MBps/5,100MBps - Samsung 980 PRO show $238.00

4TB PCIe 4.0 NVMe SSD M.2 7,450/56,900MB/s - Samsung 990 PRO show $445.00

4TB SSD M.2 NVMe SSD - 7300MB/6600MB - WD Black show $428.00

Additional Hard Drives

1TB PCIe 4.0 NVMe SSD M.2 7,000MBps/5,000MBps - Samsung 980 PRO show $165.00 each

2TB PCIe 4.0 NVMe SSD M.2 7,000MBps/5,100MBps - Samsung 980 PRO show $238.00 each

4TB PCIe 4.0 NVMe SSD M.2 7,450/56,900MB/s - Samsung 990 PRO show $445.00 each

4TB SSD M.2 NVMe SSD - 7300MB/6600MB - WD Black show $428.00 each

1.0TB SSD SATA 6.0Gb/s 560/530MB/s 2.5" - Samsung 870 EVO show $158.00 each

2.0TB SSD SATA 6.0Gb/s 560/530MB/s 2.5" - Samsung 870 EVO show $240.00 each

4.0TB SSD SATA 6.0Gb/s 560/530MB/s 2.5" - Samsung 870 EVO show $488.00 each

Raid Controller

Configure NVMe RAID 0 (Striping) - REQUIRES 2 M.2 NVMe DRIVES OF SAME MODEL AND SIZE and M.2 Adapter. show $0.00 each

Configure NVMe RAID 1 (Mirroring) - REQUIRES 2 M.2 NVMe DRIVES OF SAME MODEL AND SIZE and M.2 Adapter show $0.00 each

Cable

Add 1 DB9 Serial Port 9-pin Serial to 10-pin Header 16" show $7.00 each

Add 2 USB 3.x A Female Ports via internal USB header cable show $25.00 each

TPM 2.0 Module - SPI Capable, 2x6 pin SLB9670 FW7.63 Controller TPM Header Key, SPI Bus. show $43.00 each

Plug-In Boards

4-Port USB 3.2 Gen 1 PCIe Card - PCIe x1, Full-Height Only show $30.00 each

Serial PCIe Card - 2 Ports, Full Height or Low Profile show $23.00 each

2 Port DB9 Serial PCI-Express 2.0 x1 Card - high performance RS-422/485 serial interface controllers show $94.00 each

Serial PCIe Card with Fan-out Cable - 4 Ports, Full Height and Low Profile.. show $43.00 each

Parallel PCIe Card - 1 Port, Full Height or Low Profile show $31.00 each

Networking

PCIe x1 - 10/100/1000/2500Mbps Single Port Network Adapter - Full Height or Low Profile show $109.00 each

PCIe x4 - 10Gbps Dual Port Network Adapter - Full Height or Low Profile show $415.00 each

PCIe x8 Dual Port Intel Ethernet Converged Network Adapter X520-DA2 - Copper SFP+ Direct Attached - Lo show $580.00 each

PCIe x8 Dual Port Intel Ethernet Converged Network Adapter X520-SR2 - Optical Fiber - Low-profile/Full show $783.00 each

PCIe x8 - 10Gbps Quad Port Network Adapter - Low Profile & Full Height show $712.00 each

PCIe x8 - 10Gbps Quad Port Network Adapter - Low Profile & Full Height show $857.00 each

PCIe x8 Dual Port SFP+ Direct Attached Twinaxial Cabling Intel X710-DA2 10GbE Network Adapter. - Low P show $454.00 each

PCIe x8 Quad Port ..SFP+ Direct Attached Twin Axial Cabling Intel X710-DA4 10GbE Network Adapter. - Fu show $681.00 each

Power Supply

650W SFX Form Factor Auto-Switching Power Supply, Fully Modular, 80+ Gold show $235.00

800W SFX-L Form Factor Auto-Switching Power Supply, Fully Modular, 80 Plus Titanium Certified show $337.00

1000W SFX-L Form Factor Auto-Switching Power Supply, Fully Modular, 80 Plus Platinum Certified show $422.00

Operating System

None show Included

Microsoft Windows 11 Pro Downgrade to Windows 10 Pro 64-Bit. Includes Windows 11 Product Key Only. show $219.00

Microsoft Windows 11 Professional, 64-Bit show $199.00

Microsoft Windows 11 Pro For Workstation, 64-Bit show $409.00

Ubuntu Desktop Edition Standard (Latest LTS Compatible). Community Support Only. Installation CD Not Included. show $49.00

Ubuntu Server Edition Standard (Latest LTS Compatible). Community Support Only. Installation CD Not Included. show $49.00

Red Hat Enterprise Linux Server Entry Level - Self-Support Subscription - 1 Year - 1-2 Sockets show $410.00

RED HAT Enterprise LINUX SERVER show $850.00

Warranty

One-Year Depot Warranty show $0.00

Two-Year Depot Warranty show $199.00

Three-Year Depot Warranty show $399.00

One-Year 8x5 Onsite Warranty (USA/Can) show $245.00

One Year 24x7 Onsite Warranty (USA/Can) show $299.00

Two-Year 8x5 Onsite Warranty (USA/Can) show $475.00

Two-Year 24x7 Onsite Warranty (USA/Can) show $515.00

Three-Year 8x5 Onsite Warranty (USA/Can) show $760.00

Three-Year 24x7 Onsite Warranty (USA/Can) show $805.00

Monitors

None show Included

1U Rackmount 17" LCD Keyboard Drawer, VGA with USB notebook keyboard & touch pad - Fits racks 18.5" - 27.6" DeepSpecial Order Item, Delivery approximately 3 weeks. show $952.00

1U Rackmount 17" LCD Keyboard Drawer, notebook keyboard &..touch pad, 8 port USB KVM - Fits Racks 24" - 33" Deep show $1,482.00

1U Rackmount 19" Wide Screen (1440X900) LCD drawer. VGA + HDMI with HDMI Cable. (Short Depth: 18.1") with integrated keyboard and touchpad (HDMI input show $1,058.00

1U Rackmount 19" Wide Screen (1440X900) LCD drawer. VGA + HDMI with HDMI Cable. (Short Depth: 18.1") with integrated keyboard and trackball (HDMI inpu show $1,112.00

1U Rackmount 19" Wide Screen (1440X900) LCD drawer (22.84" deep) with integrated keyboard and touchpad, and 8-port KVM (Cables not included) show $1,589.00

1U Rackmount 19" LCD Keyboard Drawer, VGA with USB notebook keyboard & touch pad - Fits 23.6"- 32.6" Deep Racks show $1,047.00

1U Rackmount 19" LCD Keyboard Drawer, notebook keyboard &..touch pad, 8 port USB/PS2 KVM - Fits 24" - 33" Deep Racks show $1,578.00

Keyboard/Mouse

USB Keyboard/Mouse - Black/Silver show $24.00 each

Wireless Keyboard/Mouse show $49.00 each

USB Keyboard: Medical Grade True Type 104 Key Layout - Waterproof, NEMA4X/IP66 show $97.00 each

USB Mouse: Medical Grade, 1000 DPI Optical Mouse with Scroll Wheel + 2 Button, Long Cable with Seal Ca show $97.00 each

RF Wireless Medical Grade Washable Keyboard - 99 US Key Layout Waterproof, NEMA4X show $149.00 each

RF Wireless Medical Grade Waterproof Mouse, Antimicrobial Product Protection, 1000 DPI Optical Mouse w show $135.00 each

1U Keyboard/Touchpad rackmount drawer - Fits 19" Deep Racks (Mount in the Front Only), USB-Connection. show $249.00 each

1U Short Depth Rackmount keyboard drawer w/ touchpad and latching drawer. 15.7" depth. show $369.00 each

1U Short Depth Rackmount keyboard drawer w/ trackball and latching drawer. 15.7" depth. show $423.00 each

External Power

Smart LCD 1500VA 2U Rack/Tower Line-Interactive 120V UPS with LCD display, Expandable Runtime, USB & S show $610.00 each

Mounting Option

20" Adjustable Slide Rails - Fits 22.3" - 31" deep cabinet. Support chassis up to 23" deep show $51.00 each

24" Adjustable Slide Rails - Fits 26.3" - 39" deep cabinet. Support chassis up to 27" deep show $57.00 each

26" Adjustable Slide Rails - Fits 28.4" - 39" deep cabinet. Supported chassis up to 29" deep show $65.00 each

* Required Fields

Technical Specifications

MotherBoard Specifications:

Motherboard Model
Motherboard Type: SSI CEB
Supported CPU
Number of Processors: 1
Processor Type: AMD Socket sWRX8 for Ryzen™ Threadripper™ PRO Series
Chipset
Chipset: AMD WRX80
Memory
Memory Type: DDR4 3200MHz
Memory Type: ECC Registered
DIMMS: 8
Maximum Memory: 2048GB
On Board Audio
Audio Type: Realtek® ALC4080 codec
On Board Video
Video Chipset: ASPEED AST2600 BMC
Video on IO: VGA
VGA Port Out: 1
LAN
LAN Ports: 4
LAN Type: 10GbE + 10GbE + 1GbE + IPMI
LAN Chipset: Intel® X550-AT2 10GBase-T
Second LAN Chipset: Intel® X550-AT2 10GBase-T
Third LAN Chipset: Intel® i210
Fourth LAN Chipset: 10/100/1000 management LAN
Wireless LAN: No Integrated WLAN
Drive Interface
SATA III Ports (6GB): 4
SAS 6G Ports: 3
RAID
RAID Type: Software RAID
RAID Levels Supported on Motherboard: 0, 1, 5, 10
Expansion Slots
PCI Express x16 Slots On Motherboard: 7
M.2 Slot Specs
Total M.2 NVMe SSD Slots: 2
M.2 Slot #1 Specs
M.2 SATA SSD
PCIe Signal
2242 - 22 mm x 42 mm.
2280 - 22 mm x 80 mm.
M.2 Slot #2 Specs
M.2 SATA SSD
PCIe Signal
2242 - 22 mm x 42 mm.
2280 - 22 mm x 80 mm.
Rear IO
USB 3.2 Gen 2 Type A Ports (on IO): 5
USB 3.2 Gen 2 Type C Ports (on I/O): 1
Audio on IO
Headers
USB 3.2 Gen 1 Ports (on Headers): 4
Serial (via Headers): 1
FAN Connectors: 9
TPM Support: Via 2.0 Header
Environmental
Operating Temperature: 10ºC to 40ºC (50ºF to 104ºF )
High Humidity: 95%
Low Humidity: 20%
Operating System Support
Windows 10 Home (64 Bit)
Windows 10 Pro (64-Bit)
Windows 10 Pro WS (64-Bit)
SL-Windows 11PRO to 10PRO 64bit
Windows 11 Pro (64 Bit)
Windows 11 Pro for WS (64 Bit)
RED HAT Enterprise LINUX SERVER BASIC
RED HAT Enterprise LINUX SERVER STANDARD
LINUX Ubuntu Desktop
Ubuntu Server Edition
Compliance of Component
CE
Other Features
Features:
Expansion Slots

Slot_7: 1 x PCIe x16 (Gen4 x16) slot
Slot_6: 1 x PCIe x16 (Gen4 x16) slot
Slot_5: 1 x PCIe x16 (Gen4 x16) slot
Slot_4: 1 x PCIe x16 (Gen4 x16) slot
Slot_3: 1 x PCIe x16 (Gen4 x16) slot
Slot_2: 1 x PCIe x16 (Gen4 x8) slot
Slot_1: 1 x PCIe x16 (Gen4 x16) slot

Video

Integrated in Aspeed^® AST2600
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp

TPM

1 x TPM header with SPI interface
Optional TPM2.0 kit: CTM010
Motherboard Warranty: 1 Year
