SL-1U-C262SCL-LU

Name: SL-1U-C262SCL-LU
SKU: SL-1U-C262SCL-LU
Price: 4085.00 USD

1U Rack Mount Server - Rackmount featuring Intel C262 Chipset, Intel® Xeon®6 6300-Series / Intel® Xeon® E-2400 Processors, LGA1700, 2x 1GbE + 1GbE LAN, 2x Serial, Up to 128GB RAM, 6x USB 2.0 Ports ( 2 Rear, 4 Internal Headers ), 4x USB 3.2 Gen 1 Ports ( 2 Rear, 2 Internal Headers ), Power Supply 350W Multi-output power supply Platinum level.

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Type:

1U Rack Mount Server
Depth: 14.50", Max Card Depth: 12.28"

Motherboard:

Featuring Intel C262 Chipset and Intel® Xeon®6 6300-Series / Intel® Xeon® E-2400 Processors, LGA1700 processor
Full Height Slots:
LAN: 2x Ports (1GbE + 1GbE)
RAID: 0,1
Video: 1x VGA
Audio: No Onboard Audio
Ports:
6x USB 2.0 Ports ( 2 Rear, 4 Internal Headers )
4x USB 3.2 Gen 1 Ports ( 2 Rear, 2 Internal Headers )
2x COM Ports (1 RS232 Rear, 1 RS232 Internal Headers)
See specifications for more ports
Operating Temperature: 0ºC to 50ºC (32ºF to 122ºF)

Also Included:

Processor: Intel Xeon E-2414 - 2.6 GHz - 4 cores - 4 threads - 12 MB cache - E-2400 Series (55W)
Memory: 2 x 16GB DDR5 5600MHz ECC Unbuffered RAM (Requires Intel Core i7/i9 or Xeon Processors)
Hard Drive: 500GB M.2 2280 NVMe SSD or greater 5,000/3,000MB/s
Power Supply: 350W Multi-output power supply Platinum level
Operating System: Not Included - See options below
Warranty: One-Year Depot Warranty

Configure

Expedite

None show Included

Rush Order - Rush order handling, assembly and testing. Shipping not included. show $100.00

Fast, Fastest. Configure your computer with all QuickShip components and Rush your order for Fastest assembly time. Configure with all QuickShip components for Fast Assembly time.

Processor

Intel Xeon E-2414 - 2.6 GHz - 4 cores - 4 threads - 12 MB cache - E-2400 Series (55W) show $663.00

Intel Xeon E-2434 - 3.4 GHz - 4 cores - 8 threads - 12 MB cache - E-2400 Series (55W) show $748.00

Intel Xeon E-2436 - 2.9 GHz - 6-cores - 12 threads - 18 MB cache - E-2400 Series (65W)Special Order Item, Delivery approximately 5 weeks. show $880.00

Intel Xeon E-2456 - 3.3 GHz - 6-cores - 12 threads - 18 MB cache - E-2400 Series (80W)Special Order Item, Delivery approximately 5 weeks. show $750.00

Intel Xeon E-2468 - 2.6 GHz - 8 cores - 16 threads - 24 MB cache - E-2400 Serie (65W) show $830.00

Intel Xeon E-2486 - 3.5 GHz - 6-cores - 12 threads - 18 MB cache - E-2400 Series (95W) show $1,598.00

Intel Xeon E-2478 - 2.8 GHz - 8-cores - 16 threads - 24 MB cache - E-2400 Series (80W)Part ETA Varies – Ask Sales show $944.00

Intel Xeon E-2488 - 3.2 GHz - 8-cores - 16 threads - 24 MB cache - E-2400 Series (95W)Part ETA Varies – Ask Sales show $1,020.00

Memory

x 16GB DDR5 5600MHz ECC Unbuffered RAM (Requires Intel Core i7/i9 or Xeon Processors) show $935.00

x 32GB DDR5 5600MHz ECC Unbuffered RAM (Requires Intel Core i7/i9 or Xeon Processors) show $1,998.00

CD/DVD/OpticalDrive

None show Included

Slim SATA DVDRW Drive show $62.00

External USB DVD ReWriteable Drive show $57.00

Additional Hard Drives

2.5" SATA SSD

1TB 2.5" Internal SSD, SATA 3.0 6.0Gb/s, TLC NAND Flash ,up to 535/515 MB/s read/write speeds, MTBF 2, show $301.00 each

2TB 2.5" SATA SSD 560/510MB/s 6Gb/s Premium Samsung, Micron or Kingston Unit show $370.00 each

250GB SSD SATA 6.0Gb/s 560/530MB/s 2.5" - Samsung 870 EVO show $210.00 each

500GB SSD SATA 6.0Gb/s 560/530MB/s 2.5" - Samsung 870 EVO show $332.00 each

1TB SSD SATA 6.0Gb/s 560/530MB/s 2.5" - Samsung 870 EVO show $446.00 each

2.0TB SSD SATA 6.0Gb/s 560/530MB/s 2.5" - Samsung 870 EVO show $725.00 each

4TB SSD SATA 6.0Gb/s 560/530MB/s 2.5" - Samsung 870 EVO show $1,924.00 each

3.5" SATA HDD

4.0TB SATA 6Gb/s 7200RPM 128MB 3.5" - EXOS 7E8 Series show $617.00 each

8.0TB SATA 6Gb/s 7200RPM 256MB 3.5" - EXOS 7E10 Series Part ETA Varies – Ask Sales show $587.00 each

12TB SATA 6Gb/s 7200RPM 256MB 3.5" - EXOS X18 Series show $674.00 each

16TB SATA 6Gb/s 7200RPM 256MB 3.5" - EXOS X18 Series show $946.00 each

20TB SATA 6Gb/s 7200RPM 256MB 3.5" - Seagate Skyhawk AI Series show $1,159.00 each

24TB Seagate 7200 RPM 512MB Cache SATA 6.0Gb/s 3.5" Internal Hard Drive Bare Drive show $1,450.00 each

26.0TB SATA 6Gb/s 7200RPM 512MB 3.5" - WD GOLD Series show $2,016.00 each

26TB SATA 6Gb/s 7200RPM 512MB 3.5" - WD Purple Pro for Surveillance Storage show $1,721.00 each

28TB SATA 6Gb/s 7200RPM 512MB 3.5" - Seagate IronWolf Pro Series show $2,349.00 each

32TB SATA 6Gb/s 7200RPM 512MB Cache 3.5" HDD - Seagate Skyhawk AI Series show $1,960.00 each

Raid Controller

None show Included

Configure RAID 0 (Striping) - REQUIRES 2 SATA DRIVES OF SAME MODEL AND SIZE show $0.00

Configure RAID 1 (Mirroring) - REQUIRES 2 SATA DRIVES OF SAME MODEL AND SIZE show $0.00

Cable

COM Port (Serial Port) Cable, 9-pin, w/ Standard-Height Bracket show $20.00 each

TPM 2.0 Module - SPI capable with Infineon 9670 controller with vertical form factor Part ETA Varies – Ask Sales show $75.00 each

Add 2 USB 3.0 Ports to System via internal cable show $40.00 each

Riser Card

Optional Riser Card Not Selected - Riser Required when selecting optional plug-in board(s) show $0.00

Riser Card - 1 Slot: PCIe x16 Gen4 show $34.00

Plug-In Boards

None show Included

M.2 NVMe Adapter

M.2 NVMe Adapter - M.2 NVMe PCI-e M-key To PCI-e 3.0 x4 Card. Requires a PCIe x4 slot. show $19.00

COM Cards

Serial PCIe Card - 2 Ports, Full Height or Low Profile show $23.00

4 Port DB9 RS-422/485 Serial PCI-Express 2.0 x1 Card, Single Slot with Fan Out Serial Cable - Full Height and Low Profile Compatible show $99.00

Serial PCIe Card with Fan-out Cable - 4 Ports, Full Height and Low Profile show $43.00

Parallel Printer (LPT1)

1 Port DB25 Parallel Printer (LPT1) PCI-Express 2.0 x1 Card show $31.00

Parallel PCIe Card with EPP mode - 1-Port, Full Height show $89.00

USB Cards

4-Port USB 3.0 Gen 1 PCIe Card - PCIe x1, Full-Height Only VIA Chipset - Windows 11/10/8.1/8/7/Vista/XP/Server and LinuxPart ETA Varies – Ask Sales show $28.00

Firewire PCIe

Audio Card

Sound Blaster Audigy FX 5.1 PCIe Sound Card with 600 ohm Headphone Amp show $87.00

Add-In Graphic Card

None show Included

NVIDIA RTX A400 4GB GDDR6, PCI Express 4.0 x16 - 4x Mini DisplayPort - Low Profile and Full Height Compatible show $312.00

NVIDIA RTX A1000 8GB GDDR6, PCI Express 4.0 x16 - 4x Mini DisplayPort - Low Profile and Full Height Compatible show $754.00

Operating System

None show Included

Ubuntu Desktop Edition Standard (Latest LTS Compatible). Community Support Only. Installation CD Not Included. show $49.00

Ubuntu Server Edition Standard (Latest LTS Compatible). Community Support Only. Installation CD Not Included. show $49.00

Red Hat Enterprise Linux Server Entry Level - Self-Support Subscription - 1 Year - 1-2 Sockets show $410.00

RH00004 - Red Hat Enterprise Linux Server, Standard (2 sockets, stackable) for servers 32/64-bit x86. Standard Support service level show $1,124.00

Red Hat Enterprise Linux WS - Standard Subscription - 1 Year - 1-2 Sockets show $395.00

Productivity Software

Monitors

None show Included

1U Rackmount 17" LCD Keyboard Drawer, VGA with USB notebook keyboard & touch pad - Fits racks 18.5" - 27.6" DeepPart ETA Varies – Ask Sales show $1,069.00

1U Rackmount 17" LCD Keyboard Drawer, notebook keyboard &..touch pad, 8 port USB KVM - Fits Racks 24" - 33" DeepPart ETA Varies – Ask Sales show $1,631.00

1U Rackmount 19" Wide Screen (1440X900) LCD drawer. VGA + HDMI with HDMI Cable. (Short Depth: 18.1") with integrated keyboard and touchpad (HDMI inputPart ETA Varies – Ask Sales show $1,218.00

1U Rackmount 19" Wide Screen (1440X900) LCD drawer. VGA + HDMI with HDMI Cable. (Short Depth: 18.1") with integrated keyboard and trackball (HDMI inpuPart ETA Varies – Ask Sales show $1,272.00

1U Rackmount 19" Wide Screen (1440X900) LCD drawer (22.84" deep) with integrated keyboard and touchpad, and 8-port KVM (Cables not included)Part ETA Varies – Ask Sales show $1,780.00

1U Rackmount 19" LCD Keyboard Drawer, VGA with USB notebook keyboard & touch pad - Fits 23.6"- 32.6" Deep RacksPart ETA Varies – Ask Sales show $1,177.00

1U Rackmount 19" LCD Keyboard Drawer, notebook keyboard &..touch pad, 8 port USB/PS2 KVM - Fits 24" - 33" Deep RacksPart ETA Varies – Ask Sales show $1,738.00

Keyboard/Mouse

Keyboard and Mouse Combo

USB Keyboard/Mouse - Black/Silver show $27.00 each

Wireless Keyboard/Mouse show $53.00 each

Medical Grade Keyboard

USB Keyboard: Medical Grade True Type 104 Key Layout - Waterproof, NEMA4X/IP66 show $129.00 each

Medical Grade Mouse

USB Mouse: Medical Grade, 1000 DPI Optical Mouse with Scroll Wheel + 2 Button, Long Cable with Seal Ca show $102.00 each

RF Wireless Medical Grade Waterproof Mouse, Antimicrobial Product Protection, 1000 DPI Optical Mouse w show $143.00 each

Rackmount Keyboard Drawer

1U Keyboard/Touchpad rackmount drawer - Fits 19" Deep Racks (Mount in the Front Only), USB-Connection. show $286.00 each

1U Short Depth Rackmount keyboard drawer w/ touchpad and latching drawer. 15.7" depth. Part ETA Varies – Ask Sales show $431.00 each

1U Short Depth Rackmount keyboard drawer w/ trackball and latching drawer. 15.7" depth. Part ETA Varies – Ask Sales show $485.00 each

External Power

None show Included

Smart LCD 1500VA 2U Rack/Tower Line-Interactive 120V UPS with LCD display, Expandable Runtime, USB & Serial portsSpecial Order Item, Delivery approximately 1 weeks. show $785.00

Mounting Option

None show Included

* Required Fields

Technical Specifications

MotherBoard Specifications:

Motherboard Model
Motherboard Type: MicroATX
Supported CPU
Number of Processors: 1
Processor Type: Intel® Xeon®6 6300-Series / Intel® Xeon® E-2400 Processors, LGA1700
Chipset
Chipset: Intel C262 Chipset
Memory
Memory Type: DDR5 4400MHz
Memory Type: ECC Unbuffered
DIMMS: 4
Maximum Memory: 128GB
On Board Audio
Audio Type: No Onboard Audio
On Board Video
Video Chipset: ASPEED AST2600 BMC
Video on IO: 1x VGA
VGA Port Out: 1
LAN
LAN Ports: 2
LAN Type and IPMI: 1GbE + 1GbE
LAN Chipset: Intel® i210
Second LAN Chipset: Intel® i210
Wireless LAN: No Integrated WLAN
Drive Interface
SATA III Ports (6GB): 8
RAID
RAID Type: Software RAID
RAID Levels Supported on Motherboard: 0, 1, 5, 10
M.2 Slot Specs
Total M.2 NVMe SSD Slots: 1
M.2 Slot #1 Specs
PCIe Signal
2280 - 22 mm x 80 mm.
22110 - 22 mm x 110 mm.
Rear IO
USB 2.0 Ports (on IO): 2
USB 3.2 Gen 1 Type A Ports (on IO): 2
Serial (Rear IO): 1
Headers
USB 2.0 Ports (on Headers): 4
USB 3.2 Gen 1 Ports (on Headers): 2
USB 3.0 Type A Interal: 1
Serial (via Headers): 1
FAN Connectors: 7
Chassis Intrusion
TPM Support: Via 2.0 Header
Environmental
Operating Temperature: 0ºC to 50ºC (32ºF to 122ºF )
High Humidity: 90%
Low Humidity: 8%
Operating System Support
Windows Server 2022 STD
RED HAT Enterprise LINUX SERVER BASIC
RED HAT Enterprise LINUX WORKSTATION STANDARD
RED HAT Enterprise LINUX SERVER STANDARD
LINUX Ubuntu Desktop
Ubuntu Server Edition
Compliance of Component
CE
FCC
Other Features
Features:
PCIe
2 PCIe 4.0 x4 (in x8 slot),
1 PCIe 5.0 x8,
1 PCIe 5.0 x8 (in x16 slot)

M.2
M.2 Interface: 1 PCIe 4.0 x4
Form Factor: 2280/22110
Key: M-Key
Motherboard Warranty: 1 Year
