[TEST PRODUCT Short Description] CHENBRO RM42300-F 1.2 mm SGCC 4U Rackmount Server Case 3 External 5.25" Drive Bays
[TEST PRODUCT Features] CHENBRO RM42300-F 1.2 mm SGCC 4U Rackmount Server Case 3 External 5.25" Drive Bays
CHENBRO RM42300-F 1.2 mm SGCC 4U Rackmount Server Case 3 External 5.25" Drive Bays
- [TEST PRODUCT SPECIFICATIONS]
- PWRBTN (Power Switch):
Connect to the power switch on the chassis front panel. You may configure the way to
turn off your system using the power switch. - RESET (Reset Switch):
Connect to the reset switch on the chassis front panel. Press the reset switch to restart
the computer if the computer freezes and fails to perform a normal restart. - PLED (System Power LED):
Connect to the power status indicator on the chassis front panel. The LED is on when
the system is operating. The LED keeps blinking when the system is in S1/S3 sleep
state. The LED is off when the system is in S4 sleep state or powered off (S5). - HDLED (Hard Drive Activity LED):
Connect to the hard drive activity LED on the chassis front panel. The LED is on
when the hard drive is reading or writing data. - The front panel design may differ by chassis. A front panel module mainly consists
of power switch, reset switch, power LED, hard drive activity LED, speaker and etc.
When connecting your chassis front panel module to this header, make sure the wire
assignments and the pin assignments are matched correctly.
