SL-MB-CL-H61-BA
Microbox PC - Embedded PC featuring Long Production Cycle Motherboard (Through Q2 2018) with Intel H61 Chipset, 3rd Gen Core i3/i5/i7 (LGA1155, 'Ivy Bridge'), 2x GB (10/100/1000) LAN, HDD or SSD, 2x Serial, Up to 16GB RAM, 7x USB 2.0, 5x Expansion Slots, Dimensions of Enclosure: 15.80"L x 9.45"W x 6.10"H, 400W Power Supply
10 Weeks Lead Time.
Type:
- Microbox PC
- Dimension: 15.80" x 9.45" x 6.10"
Motherboard:
- Featuring Intel H61 Chipset and 3rd Gen Core i3/i5/i7 (LGA1155, 'Ivy Bridge') processor
- Long Production Cycle Motherboard (Through Q2 2018)
- Full Height Slots:
4 - PCI
1 - ISA - LAN: 2xGB (10/100/1000)
- Video: VGA + DVI-D
- Audio: Onboard Audio
- Ports:
7x USB 2.0 Ports ( 2 Front, 1 Rear, 4 via internal headers)
2x COM Ports (Rear)
1x Parallel Port (Headers)
3x Firewires (2 Rear, 1 on Headers)
See specifications for more ports - Operating Temperature: 10ºC to 60ºC (50ºF to 140ºF)
Also Included:
- Processor: Special Order 5 weeks - G1620 - 2.7GHz Intel Dual Core Celeron CPU - 2MB Cache, HD Graphics (55W) (ERM)
- Memory: 4GB DDR3 1333MHz RAM
- Hard Drive: 1.0TB SATA 6.0Gb/s 7200RPM 64MB 3.5" - WD Blue
- Power Supply: 400W Power Supply
- Operating System: Not Included - See options below
- Warranty: One-Year Depot Warranty
MotherBoard Specifications:
- Motherboard Model
- Motherboard Type: Single Board Computer (SBC)
- Long Production Cycle
- Long Life: YES
- EOL Date: Q2 2018
- PICMG: 1.0
- Supported CPU
- Number of Processors: 1
- Processor Type: 3rd Gen Core i3/i5/i7 (LGA1155, 'Ivy Bridge')
- Chipset
- Chipset: Intel H61 Chipset
- Memory
- Memory Type: DDR3 1333MHz
- Memory Type: Non-ECC
- DIMMS: 2
- Maximum Memory: 16GB
- On Board Audio
- Audio Type: Onboard Audio
- On Board Video
- Video Chipset: Intel HD Graphics
- Video on IO: VGA + DVI-D
- VGA Port Out: 1
- DVI-D Out: 1
- LAN
- LAN Ports: 2
- LAN Type: GB (10/100/1000)
- LAN Chipset: Realtek® RTL8111E
- Second LAN Chipset: Realtek® RTL8111E
- Wireless LAN: No Integrated WLAN
- Drive Interface
- SATA II Ports (3GB): 4
- mini PCIe
- mSATA
- half and/or full size mini PCIe card: full/half size
- Rear IO
- PS/2 Combo (Mouse/Keyboard)
- USB 2.0 Ports (on IO): 1
- Firewire Ports: 2
- Serial (Rear IO): 2
- Headers
- USB 2.0 Ports (on Headers): 6
- Firewire Ports: 1
- Parallel Ports: 1
- FAN Connectors: 2
- Digital I/O (8 Bit) On Headers
- Floppy Connectors: 1
- TPM Support: Via 1.2 Header
- Management Features
- Watch Dog
- Environmental
- Operating Temperature: 10ºC to 60ºC (50ºF to 140ºF )
- High Humidity: 95%
- Low Humidity: 5%
- Operating System Support
- Windows XP Pro (32-bit)
- Windows 7 Ultimate (64-bit)
- Windows 7 Pro (32-bit)
- Windows 7 Pro (64-bit)
- Windows 7 Pro (FES) 32-Bit
- Windows 7 Pro (FES) 64-Bit
- Windows 8.1 (32-bit)
- Windows 8.1 (64-bit)
- Windows 8.1 Pro (32-bit)
- Windows 8.1 Pro (64-bit)
- LINUX Ubuntu Desktop
- Ubuntu Server Edition
- VMWare Compatible
- Compliance of Component
- UL
- CE
- RoHS
- FCC
- Other Features
- Motherboard Warranty: 1 Year
Chassis Specifications:
- General
- Form Factor: Embedded PC
- Color: Black
- Material: Metal/Steel
- Material Thickness: 1mm
- Motherboard Compatibility: 6-Slot SBC
- Slide Rails: Optional
- Expansion
- Full Height Slots: 6
- Max Card Depth: 13.25"
- External 5.25" Bays: 1
- Internal 3.5" Bays: 1
- External 3.5" Bays: 1
- Front Ports
- USB 2.0 Port (Front): 2
- Cooling System
- Maximum Fan Count: 1
- Included Fans: 1
- Physical
- Depth: 15.80"
- Depth (Inches): 15.8
- Width: 9.45"
- Height: 6.10"
- Shipping Box - Depth: 11"
- Shipping Box - Width: 21"
- Shipping Box - Height: 15"
- Shipping Weight: 26lbs
- Compliance of Component
- UL
- CE
- RoHS
- FCC
- Other Features
- Chassis Warranty: 1 Year
